737G+ Battery Spot Welder,Battery Pack Welding Machine,with Automatic & Foot Pedal Modes and Spot Soldering Pen,Cordless Spot Welder,100-240V, for 18650/21700/LiFePO4 Cells

✔ Features:--The welding tip has the function of LED light,--Quick welding of huge power battery pack.--Intelligent dual-core full-function digital controller.--Inductive Handheld Dual-Function Capacitor Spot Welder,--Induction setting pulse burst high-energy flash welding.--Tough welding 0.3/0.25mm.★Intelligent Battery Spot WelderPower supply voltage: AC220V/ 110V+20VPower: 4.3kw (instantaneous peak)Spot welding current: 120~ 1200A (push-up welding mode)Double pulse time: 1~10msFour pulse time: 2~20msEight pulse time: 8~ 80msFixed head spot welding range: 0.15~0.35mmSpot welding range of spot welding pen: 0.05~0.2mmBody: 140x245x200mmWeight: 7kg★High-Power Moving Pulse Spot Welding Pen：Adjustable Welding Pin Spacing: 2~7mmTotal Length of Moving Spot Welding Pen: ≈580mmCable Area: 16mm²Pin Size: 1.5mm x 7mm✔ Packing List:1 x 737G+ host 1 unit1 x spot welding pen1 x wire-operated foot switch1 x Solder Pin Electric Grinder4 x Push Weld Tip Spot Welding Pins2 x Spot Welding Pen Spot Welding Needles100 x Nickel Plated Sheets2 x 20A fuse1 x Hex Wrench1 x Warranty Card1 x Instruction Manual✔Notice:1. Please use a wall socket to ensure stable power supply.2. The rated current of the release can reach 40-63A.3. Please adjust the pressure regulator to appropriate parameters to ensure the welding effec

• 【Multiple Pulse Welding Modes】Under spot welding there are 12 pulse welding modes with an LCD pulse screen for your observation The stepless welding current adjustment ranges from 50 to 800 Amps for a wider range of welding materials
• 【Dual-Function Welding】Fixed welding head and mobile welding pen to meet your needs for building battery packs of different sizes. One-button switch between two welding modes, intelligent automatic touch-sensing flash welding and foot pedal control.
• 【Cooling fan system & LED Lighting】Equipped with an intelligent cooling system, the cooling system function is activated when the internal temperature of the machine reaches the rated temperature.Improved LED lighting function makes welding operations brighter.
• 【Pedal welding】It you need precise spot weld, pedal welding is made for you. By controlling the foot pedal, precise location and timing you want is well served for you.
• 【Wide Applications】Battery butt welding: soft-pack to nickel conversion, series/parallel soft-pack batteries; Hardware butt welding: stainless steel sheets, stainless steel mesh, resistor leads, lamp leads, stainless steel and wires, DIY structures.
